Fully Automatic Paper Napkin Making Machine Fully Automatic Paper Napkin Making Machine

Fully Automatic Paper Napkin Making Machine

525000.00 - 625000.00 INR

Product Details:

  • Weight (kg) 2000KGS APPROX Kilograms (kg)
  • Dimension(L*W*H) 13*5*6 Foot (ft)
  • Click to view more
X

Price And Quantity

  • 525000.00 - 625000.00 INR
  • 1 Unit

Product Specifications

  • 13*5*6 Foot (ft)
  • 2000KGS APPROX Kilograms (kg)

Trade Information

  • Cheque, Cash in Advance (CID), Cash Advance (CA)
  • 30 Days
  • Yes
  • All India

Product Description

Our company has been engaged in manufacturing and supplying Fully Automatic Paper Napkin Making Machine. This machine is equipped with slitting unit that contains one set of slitting knives to ensure accurate cutting of napkins. It also comes with an embossing unit having metal to paper ball type in either full or border pattern. Offered machine is fully automatic and known for high production rate that saves your time, money and effort. It is integrated with band saw to cut two lanes into four stacks on delivery deck. Also fitted with static eliminator, Fully Automatic Paper Napkin Making Machine is provided with extra remote on the back side of machine so that the operator can control machine speed while feeding paper at beginning.

Specification

Paper Width

22CM, 24CM, 27CM, 30 CM, 33CM, 40CM

Printing Unit

Single Printing / Double Printing

Embossing Unit

Single Embossing / Double Embossing

Parent roll Diameter

1200 CM

Parent roll Core Inner Diameter

76 CM

Folding  Size

1/ 4 .

Speed

250000 to 300000 pieces / 10 HR ( Without Printing)

Speed

240000 to 290000 pieces / 10  HR (With Printing )

Power required

AC 220 Volts , 50Hz., 2.2 KW

Power Consuptions

5 kw / Hour

Main Motor

3 HP 1440 RPM DC

Blade Motor

1.5 HP  1440 RPM  AC

Transmission

Timing Belts ( Chain Belt Fully auto System)

Controlling  System

Frequency Drive

Machine Weight

1200 to 1400 kg

Embossing Design

As Per Requirement

Space Required

6 x 16 feet

GSM Required

17  to 24



Hard paper 18 gsm



Soft paper 15 to 17 gsm

Roll Weight ( Hard Paper)

80 to 120 kg

Roll Weight ( soft Paper)

50 to 70 kg

Power required

AC 220 Volts , 50Hz., 2.2 KW

Power Consuptions

5 kw / Hour
