Slitting Machine 30inch

Get a Price/Quote

Slitting Machine 30inch Specification

Grade
Industrial Grade

Type
Slitting Machine

Material
Mild Steel

Capacity
1000-2000 kg/hr

Computerized
Yes

Control System
PLC Control

Cutting Speed
50-120 m/min

Cutting Size
up to 30 inch (762 mm)

Cutting Thickness
0.01 mm to 1 mm

Voltage
220-380 V

Power
3 kW

Weight (kg)
1200 kg

Dimension (L*W*H)
2500 x 1700 x 1450 mm

Color
Blue

About Slitting Machine 30inch

Slitting Machine 30inch

Specification

Model	HR-114/A (30')	HR-114/B (40')
Width	66' (1676 mm)	76' (1930 mm)
Height	56' (1422 mm)	56' (1422 mm)
Length	80' (2032 mm)	80' (2032 mm)
Max. Reel Width	28' (700 mm)	38' (960 mm)
Max. Unwinding Reel Dia	40' (1000 mm)	40' (1000 mm)
Max. Rewinding Reel Dia	24' (600 mm)	24' (600 mm)
Rewinding ID	3'	3'
Max. Weight of Main Reel	500 kg	500 kg
Production Output	Min. 1ton/10HR	Min. 1ton/10HR
Paper Weight	80 GSM - 200 GSM	80 GSM - 200 GSM
Power Source	2 HP	2 HP
230 V/DC Single Phase
Type of Blade	Rotary	Rotary
Nos. of Blade	3	5
Min. Slit Width	3' (76' mm)	3' (76' mm)
Web Aligner	Optional	Optional

Efficient Duplex Rewinding System

The Slitting Machine 30inch leverages a duplex rewinder, enabling simultaneous winding of two rolls for increased productivity and minimal downtime. This efficient system is well-suited for large-scale operations handling varied materials like paper, foil, film, and sheets. Operators benefit from smooth transitions and consistent output quality.

Advanced Safety and User Controls

Equipped with emergency stop buttons, safety guards, and a user-friendly digital display, this machine prioritizes operator safety and process transparency. Its computerized PLC control allows seamless adjustments, making it easy to monitor and manage slitting parameters while ensuring safe operation even in fast-paced industrial environments.

FAQ's of Slitting Machine 30inch:

Q: How does the automatic operating mode benefit users of the Slitting Machine 30inch?

A: The automatic operating mode, managed via the PLC control system, streamlines slitting tasks by minimizing manual intervention, reducing setup times, and ensuring consistent quality. Automated controls also contribute to increased operational safety and productivity.

Q: What types of materials can be processed with this slitting machine?

A: The machine is engineered to slit a variety of materials including paper, foil, film, and sheet products. Its adjustable settings make it versatile for handling different thicknesses ranging from 0.01 mm to 1 mm and widths up to 762 mm (30 inches).

Q: When is it necessary to use the emergency stop safety feature?

A: The emergency stop should be used immediately in any situation where there is a risk to operator safety, equipment malfunction, or detected irregularity during operation. This feature quickly halts machine movement to prevent injuries or material wastage.

Q: Where is the Slitting Machine 30inch manufactured and supplied?

A: This machine is manufactured, supplied, and traded in India, meeting industrial grade standards to cater to the requirements of local and international clients in various material processing industries.

Q: What is the process for changing the blade type on this machine?

A: The machine accommodates both carbide and rotary blades. Changing the blade typically involves halting the machine, following safety protocols to remove the current blade, and securely installing the chosen blade type as per the manufacturer's guidelines. Regular blade maintenance ensures optimal cutting results.

Q: How does the computerized PLC control system enhance the slitting process?

A: The PLC control system provides advanced automation by allowing precise control of cutting speeds, sizes, and other parameters. It enables real-time monitoring, accurate adjustments, and records operational data for process optimization.
